Automating Azure VM & Arc Server Data Collection Rule Association with PowerShell

In Microsoft Sentinel or Azure Monitor deployments, onboarding virtual machines and Arc-enabled servers to Data Collection Rules (DCRs) is a key step. Doing this manually for dozens (or hundreds) of machines is time-consuming and error-prone.

To simplify this process, I created a PowerShell script that automatically:

  • Detects whether a machine is an Azure VM or an Arc-enabled server.
  • Installs the Azure Monitor Agent (AMA) if it’s missing.
  • Associates each machine with the correct Data Collection Rule (DCR).
  • Logs the success or failure for each machine to a CSV file for auditing.

This script works for Windows and Linux machines and supports multiple subscriptions.

Why This Script Matters

  • Time saving: Automates manual association of machines to DCRs.
  • Error reduction: Automatically detects machine type and OS.
  • Scalable: Processes an entire list of machines from a CSV file in one go.
  • Auditable: Exports a detailed report of results.

If you’re a Microsoft Sentinel or Azure Monitor administrator, this script will become one of your go-to tools.

How the Script Works

  1. Validate modules & Azure session: Ensures required Az PowerShell modules are installed and you’re logged in.
  2. Read machine details from CSV: Subscription IDs, Resource Groups, DCR name, machine type, etc.
  3. Detect VM or Arc server: Uses Get-AzVM and Get-AzConnectedMachine.
  4. Install AMA if missing: For VMs, uses Set-AzVMExtension; for Arc machines, uses New-AzConnectedMachineExtension.
  5. Associate with DCR: Runs New-AzDataCollectionRuleAssociation.
  6. Log results: Summarizes successes and failures to the console and an output CSV.
  7. Cloud Shell script rename: If uploading via Azure Cloud Shell, the script may upload as dcrassociation.txt. Run this command to rename it to a PowerShell script before execution:

    mv dcrassociation.txt dcrassociation.ps1

Preparing the CSV File

The script expects a CSV file with the following columns:

MachineNameVmSubscriptionIDDcrSubscriptionIDVmResourceGroupDcrResourceGroupDcrNameMachineType
MyVM0111111111-aaaa-bbbb-cccc-11111111111122222222-aaaa-bbbb-cccc-222222222222RG-VMRG-DCRMy-DCR-RuleVM
MyArcServer11111111-aaaa-bbbb-cccc-11111111111122222222-aaaa-bbbb-cccc-222222222222RG-ArcRG-DCRMy-DCR-RuleArc
  • MachineName: Exact VM or Arc machine name.
  • VmSubscriptionID: Subscription ID where the machine resides.
  • DcrSubscriptionID: Subscription ID where the DCR resides.
  • VmResourceGroup: Resource group of the VM or Arc server.
  • DcrResourceGroup: Resource group of the DCR.
  • DcrName: Data Collection Rule name.
  • MachineType: “VM” or “Arc” (optional — script auto-detects if blank).

Save this file as machines.csv.

The PowerShell Script

# Enhanced PowerShell script to associate Windows/Linux machines (VM and Arc) with DCR
# Includes robust error handling, validation, and retry logic
# CSV path is hardcoded to avoid supplying parameters at runtime, enter you csv path manually.

# ===== Configuration =====
$CsvPath           = "/home/sujit_mahakhud/machines.csv"
$RetryAttempts     = 3
$RetryDelaySeconds = 30

# ===== Module Validation =====
function Test-RequiredModules {
    $requiredModules = @(
        'Az.Accounts',
        'Az.ConnectedMachine',
        'Az.Monitor',
        'Az.Compute',
        'Az.Resources'
    )
    $missing = $requiredModules | Where-Object { -not (Get-Module -ListAvailable -Name $_) }
    if ($missing) {
        Write-Error "Missing modules: $($missing -join ', '); Install with: Install-Module $($missing -join ', ') -Force"
        exit 1
    }
    foreach ($mod in $requiredModules) {
        Import-Module $mod -Force -ErrorAction Stop
    }
}

# ===== Azure Session Validation =====
function Test-AzureSession {
    try {
        $context = Get-AzContext
        if (-not $context) {
            Write-Error "No Azure context found. Please run Connect-AzAccount."
            return $false
        }
        Get-AzSubscription -SubscriptionId $context.Subscription.Id -ErrorAction Stop | Out-Null
        return $true
    }
    catch {
        Write-Error "Azure session invalid or expired. Please re-authenticate."
        return $false
    }
}

# ===== CSV Structure Validation =====
function Test-CsvStructure {
    param([string]$FilePath)
    try {
        $csv = Import-Csv -Path $FilePath -ErrorAction Stop
        if ($csv.Count -eq 0) {
            Write-Error "CSV file contains no data rows."
            return $false
        }
        $required = @(
            'MachineName',
            'VmSubscriptionID',
            'DcrSubscriptionID',
            'VmResourceGroup',
            'DcrResourceGroup',
            'DcrName',
            'MachineType'
        )
        $cols = $csv[0].PSObject.Properties.Name
        $missing = $required | Where-Object { $_ -notin $cols }
        if ($missing) {
            Write-Error "Missing CSV columns: $($missing -join ', ')"
            return $false
        }
        return $true
    }
    catch {
        Write-Error "Failed to read CSV: $_"
        return $false
    }
}

# ===== Retry Logic =====
function Invoke-WithRetry {
    param(
        [ScriptBlock]$ScriptBlock,
        [int]$MaxAttempts = 3,
        [int]$DelaySeconds = 30,
        [string]$OperationName = "Operation"
    )
    for ($i = 1; $i -le $MaxAttempts; $i++) {
        try {
            return & $ScriptBlock
        }
        catch {
            Write-Warning ("{0} failed attempt {1}/{2}: {3}" -f $OperationName,$i,$MaxAttempts,$_.Exception.Message)
            if ($i -eq $MaxAttempts) { throw $_ }
            Start-Sleep -Seconds $DelaySeconds
        }
    }
}

# ===== Resource Retrieval =====
function Get-MachineResource {
    param(
        [string]$MachineName,
        [string]$ResourceGroup,
        [string]$MachineType
    )
    switch ($MachineType.ToLower()) {
        'vm'  { return Get-AzVM -ResourceGroupName $ResourceGroup -Name $MachineName -ErrorAction SilentlyContinue }
        'arc' { return Get-AzConnectedMachine -ResourceGroupName $ResourceGroup -Name $MachineName -ErrorAction SilentlyContinue }
        default {
            $m = Get-AzConnectedMachine -ResourceGroupName $ResourceGroup -Name $MachineName -ErrorAction SilentlyContinue
            if (-not $m) {
                $m = Get-AzVM -ResourceGroupName $ResourceGroup -Name $MachineName -ErrorAction SilentlyContinue
            }
            return $m
        }
    }
}

# ===== Agent Installation for Azure VM =====
function Install-AMAOnVM {
    param(
        [string]$Name,
        [string]$RG,
        [string]$OS,
        [object]$VM
    )
    if ($OS -ieq 'Windows') {
        $agentName = 'AzureMonitorWindowsAgent'
    }
    else {
        $agentName = 'AzureMonitorLinuxAgent'
    }
    $status = Get-AzVMExtension -ResourceGroupName $RG -VMName $Name -Name $agentName -ErrorAction SilentlyContinue
    if (-not $status) {
        Write-Output "Installing AMA on VM $Name ($OS)..."
        Set-AzVMExtension `
            -ResourceGroupName $RG `
            -VMName $Name `
            -Name $agentName `
            -Publisher 'Microsoft.Azure.Monitor' `
            -ExtensionType $agentName `
            -TypeHandlerVersion '1.0' `
            -EnableAutomaticUpgrade
    }
}

# ===== Agent Installation for Arc Machine =====
function Install-AMAOnArc {
    param(
        [string]$Name,
        [string]$RG,
        [string]$OS,
        [object]$Arc
    )
    if ($OS -match 'Windows') {
        $agentName = 'AzureMonitorWindowsAgent'
    }
    else {
        $agentName = 'AzureMonitorLinuxAgent'
    }
    $status = Get-AzConnectedMachineExtension -ResourceGroupName $RG -MachineName $Name -Name $agentName -ErrorAction SilentlyContinue
    if (-not $status) {
        Write-Output "Installing AMA on Arc machine $Name ($OS)..."
        New-AzConnectedMachineExtension `
            -MachineName $Name `
            -ResourceGroupName $RG `
            -Name $agentName `
            -ExtensionType $agentName `
            -Publisher 'Microsoft.Azure.Monitor' `
            -Location $Arc.Location `
            -EnableAutomaticUpgrade
    }
}

# ===== Main Execution =====
Write-Output "Starting DCR association..."

Test-RequiredModules

if (-not (Test-AzureSession)) { exit 1 }
if (-not (Test-CsvStructure -FilePath $CsvPath)) { exit 1 }

$machines = Import-Csv -Path $CsvPath
Write-Output "Loaded $($machines.Count) machines from $CsvPath"

$success = 0
$failure = 0
$results = @()

foreach ($m in $machines) {
    $name    = $m.MachineName.Trim()
    $subVM   = $m.VmSubscriptionID.Trim()
    $subDCR  = $m.DcrSubscriptionID.Trim()
    $rgVM    = $m.VmResourceGroup.Trim()
    $rgDCR   = $m.DcrResourceGroup.Trim()
    $dcrName = $m.DcrName.Trim()
    $type    = $m.MachineType.Trim()
    $result  = [PSCustomObject]@{
        MachineName = $name
        Status      = ''
        Details     = ''
        Time        = Get-Date
    }

    try {
        Invoke-WithRetry -ScriptBlock {
            Set-AzContext -SubscriptionId $subDCR -ErrorAction Stop
        } -OperationName 'Set DCR context' -MaxAttempts $RetryAttempts -DelaySeconds $RetryDelaySeconds

        $dcrId = "/subscriptions/$subDCR/resourceGroups/$rgDCR/providers/Microsoft.Insights/dataCollectionRules/$dcrName"
        Get-AzDataCollectionRule -ResourceGroupName $rgDCR -RuleName $dcrName -ErrorAction Stop | Out-Null

        Invoke-WithRetry -ScriptBlock {
            Set-AzContext -SubscriptionId $subVM -ErrorAction Stop
        } -OperationName 'Set VM context' -MaxAttempts $RetryAttempts -DelaySeconds $RetryDelaySeconds

        $res = Get-MachineResource -MachineName $name -ResourceGroup $rgVM -MachineType $type
        if (-not $res) { throw "Machine not found" }

        $uri = $res.Id

        if ($uri -match '/Microsoft.HybridCompute/machines/') {
            # Arc machine
            $os = if ($res.Properties.OsName) { $res.Properties.OsName } else { $res.OsName }
            Install-AMAOnArc -Name $name -RG $rgVM -OS $os -Arc $res
        }
        else {
            # Azure VM
            $os = $res.StorageProfile.OsDisk.OsType
            Install-AMAOnVM -Name $name -RG $rgVM -OS $os -VM $res
        }

        Set-AzContext -SubscriptionId $subDCR
        $assocName = "$dcrName-assoc-$name-$(Get-Date -Format 'yyyyMMddHHmmss')"
        Invoke-WithRetry -ScriptBlock {
            New-AzDataCollectionRuleAssociation `
                -AssociationName $assocName `
                -ResourceUri $uri `
                -DataCollectionRuleId $dcrId -ErrorAction Stop
        } -OperationName "Associate $name" -MaxAttempts $RetryAttempts -DelaySeconds $RetryDelaySeconds

        $result.Status  = 'Success'
        $result.Details = "Associated as $assocName"
        $success++
    }
    catch {
        $result.Status  = 'Failed'
        $result.Details = $_.Exception.Message
        $failure++
    }

    $results += $result
}

Write-Output "`nSummary: Total=$($machines.Count), Success=$success, Failed=$failure"
if ($failure -gt 0) {
    Write-Output "Failures:"
    $results | Where-Object { $_.Status -eq 'Failed' } | ForEach-Object {
        Write-Output "- $($_.MachineName): $($_.Details)"
    }
}

$exportPath = "$env:TEMP/DCR_Assoc_Results_$(Get-Date -Format 'yyyyMMddHHmmss').csv"
$results | Export-Csv -Path $exportPath -NoTypeInformation

Write-Output "Results exported to $exportPath"
Write-Output "Script completed."

Running the Script in Azure PowerShell

You can run the script in Azure Cloud Shell or on your local machine with the Az PowerShell modules installed.

Option 1: Azure Cloud Shell

  1. Open the Azure Portal.
  2. Click the Cloud Shell icon in the top navigation bar.
  3. Choose PowerShell as your shell type.
  4. Upload both files (script and CSV):
    • Click the Upload/Download icon in Cloud Shell.
    • Upload dcrassociation.ps1/dcrassociation.txt and machines.csv via the Upload button.
  5. If the file uploaded as dcrassociation.txt, rename it using:

    mv dcrassociation.txt dcrassociation.ps1
  6. Run the script:
Connect-AzAccount  # if not already logged in
./dcrassociation.ps1

The script will process all machines and print a summary at the end. A results CSV file will also be saved to the Cloud Shell $env:TEMP path, which you can download.

Option 2: Local PowerShell

  1. Install Az modules if not already installed:
Install-Module Az -Force
  1. Save the PowerShell script and machines.csv locally.
  2. Open a PowerShell terminal as Administrator.
  3. Authenticate:
Connect-AzAccount
  1. Run the script:
.\dcrassociation.ps1

Output & Logs

At the end, the script prints a summary such as:

Summary: Total=10, Success=9, Failed=1
Failures:
- MyArcServer02: Machine not found
Results exported to C:\Users\<you>\AppData\Local\Temp\DCR_Assoc_Results_20250926.csv
Script completed.

You can open the exported CSV to see details of each machine’s association.

Tips for Best Results

  • Ensure the account you use has the right permissions on both the VM/Arc machine and the DCR subscription.
  • Make sure Azure Monitor Agent can be installed (Windows/Linux firewall and policy permissions).
  • Double-check the machine names in your CSV match Azure exactly.

Conclusion

With this PowerShell script, you can onboard Azure VMs and Arc-enabled servers to Data Collection Rules in a fraction of the time it takes manually. It’s beginner-friendly yet powerful enough for large-scale enterprise deployments.

Download the script, prepare your CSV, and run it — your DCR associations will be automated and auditable in minutes.
